Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 1-9General Information 3045N Control Panel Button Descriptions 1. Direct Address Keys(8)Press to quickly dial Fax number s that are registered in the Phone Book. The first four entries are assigned to the keys. ■Copy ■Fa x ■Scan ■PrintUse these buttons to move to the top of each menu. Navigation/ Menu select buttons (5)Scroll up, down, forward, and back through the menus. Use the OK button to select a current setting/confirm current selection.
Job Status buttonPress to check active job status. System Switches the display to the System menus. Alpha Numeric Keypad (12)Input and delete letters and numbers.
Xerox Printer Manual
Redial/Pause buttonPress the button to recall the last Fax number used or to insert pauses in Fax numbers. Speed Dial buttonPress to access directories of group or individual Fax telephone numbers. Wake Up / Energy Saver buttonWhen illuminated, indicates Low Power Mode.
Press to move to Ready to Print from Energy Saver mode. C l e a r A l l A C buttonPress to go back to the top menu of each service (Copy, Fax). Then, each setting becomes default for each service.
Stop button Stops the current job. Start button Starts the current job. D a t a L E D Error LEDIndicates the status of the printer – power and ready-to- print. When illuminated, indicates an error.
Clear button Deletes entries made on the Control Panel 15. Address Book buttonMove to Address Book menu for Fax and Email. Back button Move back to previous screen. LCD Indicates printer status, warnings, and error messages. 12 34 5361 9 101-105.
1-10 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service General Information Media Path Main Tray When feeding from the Main Tray, the Feed Roller rotates, driven by the Main Motor driving the Main Drive Assembly and controlled by the Feed Solenoid, to feed the sheet to the position where it is nipped between the Feed Roller and the Separator Pad. As the Feed Roller rotates, the feed roller cams rotate to lift the Bottom Plate via the follower arms to the position for sheet feeding. Bypass Tray The media path from the Main Tray and Bypass Tray are the same.
The sheets loaded in the Bypass Tray are positioned nearer the Feed Roller, and have higher priority in feeding if both the Main Tray and Bypass Tray contain media. S3040-106: Sensors: Paper Path Drum Heat Roller Pressure Belt Exit Sensor Exit Roller Registration Roller (Pinch) Registration Sensor Separator Pad Assembly Feed RollerRegistration Roller (Rubber)Transfer Roller s3040-107 Feed Roller Paper (MFP) Paper (PSI) Bottom Plate Holder Assembly Pad. Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 1-11General Information ADF Media in the document tray is conveyed through the feed roller and takeaway roller. The sheet is nipped between the feed roller and the ADF Separator Pad while feeding into the ADF. Inside the ADF, the sheet is fed by the takeaway roller, rotating by torque from the ADF motor. When the sheet reaches the Scanner Home Position in the carriage assembly, it is scanned.
When the scan completes, the sheet is ejected to the output tray of the ADF by the exit roller. The exit roller is driven by torque from the ADF Motor.
Xerox Service Manual 2950 John
Exit Roller Home Position (CVT Position)Takeaway Roller Nudger RollerFeed Roller Feed SensorDocument Sensor ADF Separator Pad: Paper Transfer: Paper Sensors s3040-108. 1-14 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service General Information Major Components Sensors The printer contains sensors of various types that perform a variety of functions. Some sensors track media along the media path to detect jams. Other sensors detect the Toner Cartridge, monitor toner density, stop printer activity if the Rear Door is open (interlock) and monitor fusing temperature.
Registration Sensor The Registration Sensor detects the leading edge of the print medium has reached the registration section.Exit Sensor Located in the Fuser, the exit sensor detects media passing through the Fuser. Rear Door Interlock Switch Detects Rear Door position. Interrupts DC power to the printer (+24VDC) when the Rear Door is opened. Toner Cartridge CRUM Monitors print quanity to alert the user when Toner Cartridge level is low. S3040-113 Feed Solenoid Registration Sensor Feed Roller Exit SensorRear Door Interlock.
Phaser 3010/3040/WorkCentre 3045 Service Xerox Internal Use Only 1-15General Information Drive. Main Drive Assembly A gear set used to transfer drive from the Main Drive Motor to feed media through the media path.Main Drive Motor Provides drive to move media trough the media path and Fuser.Toner Motor Provides drive to supply toner to the xerographics assembly.Feed Solenoid Transmits the torque from the Main Drive Assembly to the Feed Roller. S3040-114 Main Drive Assembly Main Drive MotorToner Motor Transfer Roller.
1-16 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service General Information Electrical.IP Board The Image Processor Board is the print controller. The IP Board converts print data to image data.MCU Board Controls the print operation based on communication with the print controller and on the information from the sensors or switches.HVPS Supplies high voltage to the xerographic assembly and Transfer Roller.LVPS Supplies the AC power from the power supply to the heater section of the Fuser and generates stable low DC voltage to be used by the logic circuits and other components.Power Switch Assembly Power switch and AC inlet harness providing AC to the LVPS and Fuser.USB Board Porvides a USB interface for thumbdrives.
Wireless Interface Board IEEE wireless ethernet interface board.FAX Board FAX MODEM board for FAX transmissions. 1-18 Xerox Internal Use Only Phaser 3010/3040/WorkCentre 3045 Service General Information Consumables Consumables consist of a single Toner Cartridge. The Toner Cartridge (except starter cartridges) has a CRUM (Customer Replaceable Unit Monitor) to record regional and toner usage information. The CRUM maintains a count of the amount of toner consumed. When the count reaches set values, warning and error messages appear to notify the user when near and end of life status is reached.
The Toyota HiAce (pronounced as 'High Ace') is a light commercial van produced by the. All came with a standard 5-speed manual transmission. Used 1992 TOYOTA HIACE VAN BF483893 for Sale SOLD. MILEAGE *69825km*!! SUPERB 1RZ ENGINE WITH MANUAL TRANSMISSION!! Import Best Quality Japan Reconditioned Toyota Hiace Van Direct from Japan at Lowest. 1 KM; 2,000 CC; Petrol; Manual; Right Hand Drive; Van-minivan. 2018 toyota hiace van. Toyota Hiace Super Custom ZR1 Petrol Engine Has Electric Fuel Pump In Tank. Car specification: Toyota Hiace commuter van, manual, 2.8 litre deisel, 1994.
Life ratings are based on A-size sheets at 5% coverage. Note Starter capacity cartridges are packaged with the printer when shipped from the factory. These starter cartridges are not available for order. Toner CartridgeCapacity Starter Capacity 700 pages Standard Capacity 1,000 pages High Capacity 2,300 pages.
